BOECO Trinocular Microscope (with camera port) – BM-190/T/SP
Advanced biological Microscope for educational, teaching, life science and clinical applications.
View Product Specifications
- Magnification: 40X – 1600X
- Optical System: Siedentopf Trinocular Viewing Head, 30° inclined, 360° rotatable, interpupillary distance 47–78 mm, left diopter adjustable, with dedicated camera port for digital imaging and video recording
- Nosepiece: Backward quadruple revolving nosepiece
- Eyepiece: Pair Eyepiece WF 10X / 18 mm Widefield
- Objectives: BOECO Semi-plan Achromat DIN Objectives 4X/0.10, 10X/0.25, 40X/0.65 (S), 100X/1.25 (S, Oil)
- Stage: Double-layer mechanical specimen stage, 140 × 140 mm, moving range 75 × 50 mm, right-hand stage handle
- Focusing: Low-position coaxial coarse and calibrated fine focus control, graduation reading 2 microns per division, total focusing range 25 mm, safety stop unit
- Condenser: Abbe Brightfield condenser, N.A. 1.25, integrated iris diaphragm and filter tray, rack & pinion height adjustment
- Illumination: S-LED illumination system with adjustable brightness
- Camera Compatibility: Third trinocular port for microscope camera connection, image capture, and video documentation
- Body / Power: Sturdy body with supportive rubber base and built-in power supply, 100–240V, 50/60 Hz
- Supplied With: Dust cover, green filter, immersion oil, instruction manual
- Dimension: 208(W) × 266(D) × 370(H) mm
- Weight: Net weight 6.9 / 7.2 kg
- Packing: Styrofoam shelf in a cardboard box
